Outer Axle Seal

Te20, TO20, TO30

TO35, FE35, 50, 135, 148, 150, 240, 550

MF165, 168, 175, 178, 185, 188
MF250, 265, 275, 290, 565, 575
590, 595, 675, 690, 698

Inner Axle Seal

Te20 (from 325001), TO30 (19 Spline Axle )

TO35, MF35, 50, 135, 148, 150, 240, 550

Inner Axle Seal
(dry brakes)

MF165 early MF175

ie. Dry Brakes round axle housing

See NEXT PAGE for B3783 Axle to Dry Brake Seal

Inner Axle Seal
(wet brakes)

MF165 late	ie. Wet Brakes square axle housing
MF255, 265, 275, 285, 298, 390, 398, 399, 590, 675, 690, 698, 699, 1085

Gasket (axle housing)

All MF models TO20 to MF188

Bearing (cup & cone)

Te20, TO20, TO30

MF35, 50, 135, 148, 150, 240, 550, TO35

Locking Collar

Te20, TO20, TO30

MF35, 50, 135, 148, 150, 240, 550 , TO35

Stud (rear wheel)

Te20, TO20, TO30, TO35
MF35, 50, 135, 148, 150, 240, 250, 550

MF65, 165, 168, 175
MF250, 265, 565, 575, (275, 675, 690 with 5/8" studs)

Nut (rear wheel)

TO20, TO30, TO35
Te20, MF35, MF135, MF148, 240

Bolt (Fender)

Nut (Fender)

Link Pin parallel shank

Te20 up to 325000 (through external plate)

Pin Cat. 1

Tapered
Shank

Te20 from 325001, MF35, 135, (MF148 to 605134)

Pin Cat. 2

MF148 from 605135, MF240, 250, 550

Pin Cat. 2

MF65, 165, 175

Inner Axle Housing Gasket

All MF models MF35 to MF188 (½" holes)
For Te20, TO20 use Ref 14 below.

Wheel Rim Bolt
2 7/8" x 5/8"

All MF Non-Italian models with pressed wheels

Nut 5/8" UNF
