Walterscheid Shafts
Replacement parts for WALTERSCHEID Shafts
& LARGE (STAR PROFILE) BARE-Co Shafts
 MORE PARTS FOR THIS SHAFT ON THE NEXT PAGE
SHAFT SERIES
A
B
OUTER TUBE
OUTER TUBE YOKE
OUTER JOINT

30mm
1 3/16"
3mm
1/8"
1mtr (3ft)
5ft
 = A303
= A303X5
Part No.
A10230
Part No.
A10002

41.3mm
1 5/8"
3mm
1/8"
1mtr (3ft)
5ft
 = A413
= A413X5
Part No.
A20241
Part No.
A20002

Part No.
A11241
Order
parts

BOTH TYPES
USED
CHECK SIZE
Standard for W210-W2300
Part No. A21241
Part No.
A21002
48mm
1 7/8"
4mm
5/32"
Spec. for 48mm tube
Part No. A21248
order parts


LEMON PROFILE TUBE

1mtr (3ft)
5ft
 = A484
= A484X5
Part No.
A22248
Part No.
A22002

48mm
1 7/8"
4mm
5/32"
For Lemon Profile Tube
Part No.
A35248
P400 Series - Use Bareco Guard
Quick Release Type
A35005
1 3/8" x 6 Splines
for Lemon ProfileTube
P400 Series - Use Bareco Guard
61mm
2 7/16"
4mm
5/32"
OPTIONAL
for W2400 Series.
Star Profile Tube as below
For Star Profile Tube
Part No.
A35261
P400 Series - Use Bareco Guard


Quick Release Type
A35002
1 3/8" x 6 Splines
for Star Profile Tube
P400 Series - Use Bareco Guard

STAR PROFILE

1mtr (3ft)
5ft
 = A614
= A614X5
Part No.
A23261
For Star Profile
Tube - Order
Component
Parts

Part No.
A24261

Part No.
A36261
P500 Series - Use Bareco Guard
Quick Release Type
A36002
1 3/8" x 6 Splines
A36002121
1 3/8" x 21 Splines
A36002120
1 3/4" x 20 Spline
Clamp Yoke Type
A36002538
1 3/8" x 6 Splines
A36002521
1 3/8" x 21 Splines
A36002520
1 3/4" x 20 Spline
P500 Series - Use Bareco Guard

71mm
2 13/16"
5mm
3/16"
1mtr (3ft )
5ft
 = A715
= A715X5
Part No.
A026271
P600 Series - Use Bareco Guard
A026002
1 3/8" x 6 Splines
A026002120
1 3/4" x 20 Splines
A026002121
1 3/8" x 21 Splines
600 Series - Use Bareco Guard

71mm
2 13/16"
5mm
3/16"
1mtr (3ft )
5ft
 = A715
= A715X5
Part No.
A027271
Order
Component
Parts
