PART
No. |
SIZE |
APPLICATION |
B4088 |
133mm
OD x 89mm ID 5 1/4" x 3 1/2" |
US Clutches = 970 - 5000 |
B4489 |
140mm
OD x 85mm ID 5 1/2" x 3.346" |
|
AB140 |
140mm
OD x 89mm ID 5 1/2" x 3 1/2" |
Bare-Co
and BYPY 4 Series Shaft Mounted Clutches |
B4490 |
160mm
OD x 85mm ID 6.3" x 3.346" |
|
AB160 |
160mm
OD x 96mm ID 6.3" x 3.780" |
Bare-Co and BYPY
6, 7, 8, W2600 Series Shaft Mounted Clutches Rear Facing BARE-Co B9605 Freewheel Clutch |
AW153 |
152mm
OD x 91mm ID 6" x 3.58" |
Walterscheid
K90 and K92 series clutches |
B4165 |
127mm
OD x 45mm ID 5" x 1 3/4" |
BARE-Co
Gearbox mounted 6" clutches - ie. B4164 - B4166 - B9164 Jayben - early H. Spicer Clutches |
B3721 |
165mm
OD x 63mm ID 6 1/2" x 2 1/2" |
BARE-Co
Gearbox mounted 8" clutches - ie. B3605 - B4157 - B6693 - B4669 - B6669 - B6790 Front Facing BARE-Co B9605 Freewheel Clutch |
B4087 |
146mm
OD x 89mm ID 5 3/4" x 3 1/2" |
New
Holland Baler |
AW160 |
160mm
OD x 100mm ID 6.3" x 3.937" |
Walterscheid
F/K96 Clutch |
